Zing 15KW Three Phase Hybrid Inverter - IP66

Model: ZING-TP66-15KW

PKR 530,000

Key Specifications

  • 15,000 W rated three-phase hybrid output
  • Up to 30,000 W PV input with 1,000 V maximum PV voltage
  • Dual MPPT with 200–800 V MPPT operating range
  • 40–60 V battery range; lithium-ion and lead-acid compatible
  • Maximum 280 A charging and discharging current
  • Peak off-grid output above 200% for up to 15 seconds
  • UPS switchover time under 10 ms with dual backup output
  • 98.0% maximum PV efficiency and 97.5% European efficiency
  • Standard Wi-Fi monitoring and LCD colour screen
  • IP66 protection; operating temperature from -25°C to +60°C
Data Sheet
Zing 15KW Three Phase Hybrid Inverter - IP66Zing 15KW Three Phase Hybrid Inverter - IP66Zing 15KW Three Phase Hybrid Inverter - IP66Zing 15KW Three Phase Hybrid Inverter - IP66
