Zing 12KW Three Phase Hybrid Inverter - IP66
Model: ZING-TP66-12KW
PKR 430,000
Key Specifications
- 12,000 W rated three-phase hybrid output
- Up to 24,000 W PV input with 1,000 V maximum PV voltage
- Dual MPPT with 200–800 V MPPT operating range
- 40–60 V battery range; lithium-ion and lead-acid compatible
- Maximum 250 A charging and discharging current
- Peak off-grid output above 200% for up to 15 seconds
- UPS switchover time under 10 ms with dual backup output
- 98.0% maximum PV efficiency and 97.5% European efficiency
- Standard Wi-Fi monitoring and LCD colour screen
- IP66 protection; operating temperature from -25°C to +60°C
